INAV Betaflight F4 Pro BEC BN220 GPS

F4PRO-V2-INAV

This is the all-new Omnibus F4 Pro, based on the design of the popular Omnibus F3 Pro. But the main advantage of this board is that it uses the more powerful STM F4 processor for faster cycle times. OSD module, USB card reader, low-noise MPU6000 IMU, SPI, current and voltage sensor, etc. Everything you love from Omnibus F3 Pro is available on this board.

The V2 Pro version now includes an integrated BEC so you can power this board directly from your flight battery (up to 4s).

Specifications:

• SPI Gyro MPU6000
• Onboard OSD (controlled by Betaflight, FC via SPI bus)
• MicroSD black box
• Barometer (BMP280) (off by default, contact us if you don't know how to turn it on)
• F4 processor (F405)
• 5V3A BEC
• Integrated current sensor
• Integrated video filter (provides 5V supply only, for VTX and camera)

PPM Kullanımı

If you are having problems introducing your PPM receiver to FC, here is what you need to do: You need to enable rx_seri in the GUI and turn on uart3. Save and restart the flight controller. Then check again by selecting the RX_PPM option so that your FC communicates with your PPM receiver.
